62-227ET/KK7D-3M5050X6Y62629U6/2T/EU
LED Lighting - White
- Manufacturer No:
- 62-227ET/KK7D-3M5050X6Y62629U6/2T/EU
- Manufacture:
- Everlight Electronics Co Ltd
- Package:
- 2211 (5630 Metric)
- Datasheet:
- 62-227ET/KK7D-3M5050X6Y62629U6/2T/EU
- Description:
- 5630 KK7D COOL WHITE LED 5000K 8
In Stock
59090 pcs On sales
$0
Product Parameter
- Current - Max
- 180mA
- Voltage - Forward (Vf) (Typ)
- 2.75V
- Mounting Type
- Surface Mount
- Thermal Resistance of Package
- 11°C/W
- Viewing Angle
- 120°
- Current - Test
- 65mA
- Package / Case
- 2211 (5630 Metric)
- Size / Dimension
- 0.220" L x 0.118" W (5.60mm x 3.00mm)
- Height - Seated (Max)
- 0.028" (0.70mm)
- Color
- White, Cool
- Supplier Device Package
- 2-PLCC
- Series
- 62-227ET
- CRI (Color Rendering Index)
- 80
- CCT (K)
- 5000K
- Flux @ 25°C, Current - Test
- 41lm (Typ)
- Packaging
- Digi-Reel®
- Flux @ 85°C, Current - Test
- -
- Part Status
- Active
- Lumens/Watt @ Current - Test
- 229 lm/W
