622-025-260-042

D-Sub Connectors

Manufacturer No:: 622-025-260-042
Manufacture:: EDAC Inc.
Datasheet:: 622-025-260-042
Description:: CONN D-SUB RCPT 25POS R/A SOLDER

In Stock

49 pcs On sales

$1.81

Product Parameter

Part Status: Active

Contact Material: Phosphor Bronze

Termination: Solder

Ingress Protection: -

Contact Form: -

Dielectric Material: Polyester Thermoplastic

Contact Type: Signal

Number of Positions: 25

Mounting Type: Panel Mount, Through Hole, Right Angle

Current Rating (Amps): 5A

Connector Type: Receptacle, Female Sockets

Operating Temperature: -55°C ~ 105°C

Contact Finish: Gold

Shell Material, Finish: Steel, Nickel Plated

Color: Black

Flange Feature: Housing/Shell (4-40)

Contact Finish Thickness: Flash

Series: 622

Number of Rows: 2

Material Flammability Rating: UL94 V-0

Features: Board Lock, Shielded

Voltage Rating: -

Shell Size, Connector Layout: 3 (DB, B)

Packaging: Tray

Backset Spacing: 0.318" (8.08mm)

Wire Gauge: -

Connector Style: D-Sub
