4114NXHHU-233
DC Brushless Fans (BLDC)
- Manufacturer No:
- 4114NXHHU-233
- Manufacture:
- ebm-papst Inc.
- Datasheet:
- 4114NXHHU-233
- Description:
- FAN AXIAL 24VDC 119X38MM IP68
In Stock
18 pcs On sales
$104.58
Product Parameter
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
- Features
- Auto Restart, Locked Rotor Protection
- Size / Dimension
- Square - 119mm L x 119mm H
- Approvals
- UL
- Ingress Protection
- IP68 - Dust Tight, Waterproof
- Part Status
- Active
- Current Rating (Amps)
- 0.508A
- Termination
- 2 Wire Leads
- Operating Temperature
- -13 ~ 131°F (-25 ~ 55°C)
- Bearing Type
- Ball
- RPM
- 4900 RPM
- Power (Watts)
- 13.60W
- Noise
- 60.0 dB(A)
- Voltage Range
- 12 ~ 28VDC
- Width
- 38.00mm
- Static Pressure
- 0.819 in H2O (204.0 Pa)
- Series
- 4100NU
- Voltage - Rated
- 24VDC
- Weight
- 0.882 lb (400.07 g)
- Lifetime @ Temp.
- 70000 Hrs @ 40°C
- Air Flow
- 153.0 CFM (4.28m³/min)
- Material - Blade
- Polyamide (PA), Nylon, Fiberglass Reinforced
