4112N/2H4
DC Brushless Fans (BLDC)
- Manufacturer No:
- 4112N/2H4
- Manufacture:
- ebm-papst Inc.
- Datasheet:
- 4112N/2H4
- Description:
- FAN AXIAL 119X38MM 12VDC
In Stock
25 pcs On sales
$82.38
Product Parameter
- Termination
- 3 Wire Leads
- Operating Temperature
- -4 ~ 149°F (-20 ~ 65°C)
- Bearing Type
- Ball
- Power (Watts)
- 32.00W
- RPM
- 6800 RPM
- Voltage Range
- 9 ~ 14VDC
- Noise
- 67.0 dB(A)
- Static Pressure
- -
- Width
- 38.00mm
- Voltage - Rated
- 12VDC
- Series
- 4100N
- Lifetime @ Temp.
- 62500 Hrs @ 40°C
- Air Flow
- 209.0 CFM (5.85m³/min)
- Material - Blade
- Polyamide (PA), Nylon, Fiberglass Reinforced
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
- Features
- Locked Rotor Protection, Speed Sensor (Tach)
- Size / Dimension
- Square - 119mm L x 119mm H
- Approvals
- CSA, UL
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- -
