TB400-11
Terminal Blocks - Barrier Blocks
- Manufacturer No:
- TB400-11
- Manufacture:
- Eaton-Bussmann Electrical Division
- Datasheet:
- TB400-11
- Description:
- CONN BARRIER STRP 11CIRC 0.687"
In Stock
0 pcs On sales
$0
Product Parameter
- Number of Rows
- 2
- Material Flammability Rating
- UL94 V-0
- Voltage Rating
- 600V
- Top Termination
- Screws
- Color
- Black
- Bottom Termination
- Closed
- Pitch
- 0.687" (17.45mm)
- Number of Circuits
- 11
- Series
- Magnum® TB400
- Terminal Block Type
- Barrier Block
- Features
- Flange
- Current Rating (Amps)
- 75A
- Packaging
- Bulk
- Material - Insulation
- Thermoplastic
- Wire Gauge
- 6-14 AWG
- Operating Temperature
- -40°C ~ 130°C
- Part Status
- Obsolete
- Terminal Screw Finish
- Zinc
- Barrier Type
- 2 Wall (Dual)
- Number of Wire Entries
- 22
- Mounting Type
- Chassis, Panel
- Terminal Screw Material
- Steel
