TL1105DF250Q

Tactile Switches

Manufacturer No:: TL1105DF250Q
Manufacture:: E-Switch
Datasheet:: TL1105DF250Q
Description:: SWITCH TACTILE SPST-NO 0.05A 12V

In Stock

12641 pcs On sales

$0.19

Product Parameter

Mechanical Life: 100,000 Cycles

Actuator Height off PCB, Vertical: 13.00mm

Operating Force: 250gf

Series: TL1105

Switch Function: Off-Mom

Circuit: SPST-NO

Actuator Material: Polyamide (PA), Nylon

Outline: 6.00mm x 6.00mm

Termination Style: PC Pin

Features: -

Ingress Protection: -

Packaging: Bulk

Actuator Orientation: Top Actuated

Part Status: Active

Operating Temperature: -20°C ~ 70°C

Illumination: Non-Illuminated

Contact Rating @ Voltage: 0.05A @ 12VDC

Actuator Type: Standard

Illumination Type, Color: -

Mounting Type: Through Hole

Actuator Length, Right Angle: -

Switch Travel: 0.25mm

Illumination Voltage (Nominal): -
