DGD21814S14-13
PMIC - Gate Drivers
- Manufacturer No:
- DGD21814S14-13
- Manufacture:
- Diodes Incorporated
- Package:
- 14-SOIC (0.154", 3.90mm Width)
- Datasheet:
- DGD21814S14-13
- Description:
- IC GATE DRVR HALF-BRIDGE 14SO
In Stock
0 pcs On sales
$1.32
Product Parameter
- Series
- -
- Rise / Fall Time (Typ)
- 40ns, 20ns
- Gate Type
- IGBT, N-Channel MOSFET
- Supplier Device Package
- 14-SO
- Packaging
- Tape & Reel (TR)
- Logic Voltage - VIL, VIH
- 0.8V, 2.5V
- Input Type
- Non-Inverting
- High Side Voltage - Max (Bootstrap)
- 600V
- Part Status
- Active
- Current - Peak Output (Source, Sink)
- 1.9A, 2.3A
- Channel Type
- Independent
- Mounting Type
- Surface Mount
- Package / Case
- 14-SOIC (0.154", 3.90mm Width)
- Voltage - Supply
- 10V ~ 20V
- Number of Drivers
- 2
- Driven Configuration
- Half-Bridge
- Operating Temperature
- -40°C ~ 150°C (TJ)
