1-NPT/603-1340
DC Brushless Fans (BLDC)
- Manufacturer No:
- 1-NPT/603-1340
- Manufacture:
- Delta Electronics
- Datasheet:
- 1-NPT/603-1340
- Description:
- FAN - 603-1340/WM2312TR/WM2001
In Stock
7 pcs On sales
$33.92
Product Parameter
- Features
- Speed Sensor (Tach)
- Size / Dimension
- Square - 120mm L x 120mm H
- Approvals
- CE, CSA, UL, VDE
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.680A
- Termination
- 3 Position Rectangular Connector
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
- Bearing Type
- Ball
- RPM
- 4000 RPM
- Power (Watts)
- 8.16W
- Noise
- 51.0 dB(A)
- Voltage Range
- 6 ~ 12.8VDC
- Width
- 38.00mm
- Static Pressure
- 0.602 in H2O (149.9 Pa)
- Series
- AFB
- Voltage - Rated
- 12VDC
- Weight
- 0.706 lb (320.24 g)
- Lifetime @ Temp.
- 70000 Hrs @ 40°C
- Air Flow
- 148.3 CFM (4.15m³/min)
- Material - Blade
- Plastic
- Fan Type
- Tubeaxial, Case Fan
- Material - Frame
- Plastic
