VWQBS2-Q48-S9-SIP
DC DC Converters
- Manufacturer No:
- VWQBS2-Q48-S9-SIP
- Manufacture:
- CUI, Inc.
- Package:
- 9-SIP Module, 7 Leads
- Datasheet:
- VWQBS2-Q48-S9-SIP
- Description:
- DC DC CONVERTER 9V 2W
In Stock
0 pcs On sales
$0
Product Parameter
- Part Status
- Obsolete
- Voltage - Input (Max)
- 72V
- Applications
- ITE (Commercial)
- Voltage - Input (Min)
- 18V
- Mounting Type
- Through Hole
- Current - Output (Max)
- 222mA
- Power (Watts)
- 2W
- Package / Case
- 9-SIP Module, 7 Leads
- Size / Dimension
- 1.02" L x 0.37" W x 0.49" H (26.0mm x 9.5mm x 12.5mm)
- Number of Outputs
- 1
- Type
- Isolated Module
- Voltage - Output 1
- 9V
- Series
- VWQBS2-SIP (2W)
- Voltage - Output 2
- -
- Features
- SCP
- Voltage - Output 3
- -
- Packaging
- Bulk
- Voltage - Isolation
- 1.5kV
- Efficiency
- 76%
- Operating Temperature
- -40°C ~ 85°C
