PJ-002BH

Barrel - Power Connectors

Manufacturer No:: PJ-002BH
Manufacture:: CUI, Inc.
Datasheet:: PJ-002BH
Description:: CONN PWR JACK 2.5X5.5MM SOLDER

In Stock

16809 pcs On sales

$0.74

Product Parameter

Part Status: Active

Internal Switch(s): Single Switch, Normally Closed

Termination: Solder Eyelet(s)

Dielectric Material: Polybutylene Terephthalate (PBT)

Thread Size: -

Mating Length/Depth: 0.350" (8.90mm)

Body Material: -

Current Rating (Amps): 5A

Mounting Type: Through Hole, Right Angle

Operating Temperature: -25°C ~ 85°C

Gender: Male

Connector Type: Jack

Contact Material - Plating: Silver

Series: -

Actual Diameter: 0.098" (2.50mm ID), 0.256" (6.50mm OD)

Material Flammability Rating: UL94 V-0

Features: Board Guide, Solder Retention

Voltage - Rated: 24VDC

Number of Positions/Contacts: 2 Conductors, 3 Contacts

Includes: -

Contact Material: Brass, Copper Alloy

Industry Recognized Mating Diameter: 2.50mm ID (0.098"), 5.50mm OD (0.217")

Packaging: Bulk

Insulation Color: -

Shielding: Unshielded

Mounting Feature: -

Body Color: Black

Ingress Protection: -
