CVS-1508
Speakers
- Manufacturer No:
- CVS-1508
- Manufacture:
- CUI, Inc.
- Datasheet:
- CVS-1508
- Description:
- SPEAKER 8OHM 300MW TOP PORT 87DB
In Stock
4788 pcs On sales
$2.96
Product Parameter
- Port Location
- Top
- Power - Rated
- 300mW
- Type
- General Purpose
- Frequency Range
- 1.36kHz ~ 20kHz
- Shape
- Round
- Material - Cone
- Polyester, Polyethylene Terephthalate (PET)
- Series
- CVS
- Efficiency - dBA
- 73.00
- Ratings
- Washable
- Size / Dimension
- 0.591" Dia (15.00mm)
- Impedance
- 8 Ohms
- Efficiency - Type
- Sound Pressure Level (SPL)
- Packaging
- Tray
- Material - Magnet
- Nd-Fe-B
- Technology
- Magnetic
- Ingress Protection
- -
- Part Status
- Active
- Efficiency - Testing
- 1W/1M
- Power - Max
- 500mW
- Height - Seated (Max)
- 0.295" (7.50mm)
- Termination
- PC Pins
- Frequency - Self Resonant
- 1700Hz
