CEP-2224
Alarms, Buzzers, and Sirens
- Manufacturer No:
- CEP-2224
- Manufacture:
- CUI, Inc.
- Datasheet:
- CEP-2224
- Description:
- AUDIO PIEZO INDICATOR 3-20V TH
In Stock
16791 pcs On sales
$2.5
Product Parameter
- Series
- CEP
- Voltage Range
- 3 ~ 20V
- Ratings
- -
- Operating Mode
- Single Tone
- Duration
- -
- Voltage - Rated
- 12V
- Approvals
- -
- Current - Supply
- 15mA
- Frequency
- 3.4kHz
- Driver Circuitry
- Indicator, Internally Driven
- Packaging
- Tray
- Size / Dimension
- 0.945" Dia (24.00mm)
- Input Type
- DC
- Height - Seated (Max)
- 0.374" (9.50mm)
- Technology
- Piezo
- Operating Temperature
- -30°C ~ 85°C
- Part Status
- Active
- Sound Pressure Level (SPL)
- 78dB @ 12V, 30cm
- Termination
- PC Pins
- Mounting Type
- Through Hole
- Port Location
- Top
