CXA1512-0000-000F0HM450F
LED Lighting - COBs, Engines, Modules, Strips
- Manufacturer No:
- CXA1512-0000-000F0HM450F
- Manufacture:
- Cree Inc.
- Datasheet:
- CXA1512-0000-000F0HM450F
- Description:
- LED COB CXA1512 COOL WHT SQUARE
In Stock
1003 pcs On sales
$2.83
Product Parameter
- Features
- -
- Light Emitting Surface (LES)
- 8.90mm Dia
- Lens Type
- Flat
- Lumens/Watt @ Current - Test
- 122 lm/W
- Packaging
- Tray
- Voltage - Forward (Vf) (Typ)
- 18V
- Wavelength
- -
- Flux @ Current/Temperature - Test
- 1538lm (1485lm ~ 1590lm)
- Part Status
- Active
- Configuration
- Square
- Current - Max
- 1.2A
- Type
- Chip On Board (COB)
- Viewing Angle
- 115°
- Color
- White, Cool
- Current - Test
- 700mA
- Height
- 1.70mm
- Size / Dimension
- 15.85mm L x 15.85mm W
- Series
- XLamp® CXA1512
- Temperature - Test
- 85°C
- CCT (K)
- 5000K 4-Step MacAdam Ellipse
- CRI (Color Rendering Index)
- 80
