380LX822M035J032

Aluminum Electrolytic Capacitors

Manufacturer No:: 380LX822M035J032
Manufacture:: Cornell Dubilier Electronics (CDE)
Package:: Radial, Can - Snap-In
Datasheet:: 380LX822M035J032
Description:: CAP ALUM 8200UF 20% 35V SNAP

In Stock

1600 pcs On sales

$3.63

Product Parameter

Polarization: Polar

Mounting Type: Through Hole

Package / Case: Radial, Can - Snap-In

Voltage - Rated: 35V

Series: 380LX

Lifetime @ Temp.: 3000 Hrs @ 85°C

Ratings: -

Size / Dimension: 0.984" Dia (25.00mm)

Packaging: Bulk

Height - Seated (Max): 1.457" (37.00mm)

Tolerance: ±20%

Operating Temperature: -40°C ~ 85°C

Capacitance: 8200µF

Surface Mount Land Size: -

Part Status: Active

Ripple Current @ Low Frequency: 4A @ 120Hz

Applications: General Purpose

Ripple Current @ High Frequency: 4.6A @ 20kHz

Lead Spacing: 0.394" (10.00mm)

ESR (Equivalent Series Resistance): 57mOhm @ 120Hz
