PA0109-S
Solder Stencils, Templates
- Manufacturer No:
- PA0109-S
- Manufacture:
- Chip Quik, Inc.
- Datasheet:
- PA0109-S
- Description:
- VQFP-100/TQFP-100 STENCIL
In Stock
4 pcs On sales
$11.59
Product Parameter
- Type
- TQFP
- Pitch
- 0.020" (0.50mm)
- Series
- Proto-Advantage PA
- Material
- Stainless Steel
- Thickness
- 0.0040" (0.102mm)
- Part Status
- Active
- Inner Dimension
- 0.551" L x 0.551" W (14.00mm x 14.00mm)
- Outer Dimension
- 1.300" L x 0.900" W (33.02mm x 22.86mm)
- Thermal Center Pad
- -
- Number of Positions
- 100
