NE85630-T1-A
Transistors - Bipolar (BJT) - RF
- Manufacturer No:
- NE85630-T1-A
- Manufacture:
- CEL
- Package:
- SC-70, SOT-323
- Datasheet:
- NE85630-T1-A
- Description:
- RF TRANS NPN 12V 4.5GHZ SOT323
In Stock
0 pcs On sales
$0
Product Parameter
- Gain
- 9dB
- Noise Figure (dB Typ @ f)
- 1.2dB @ 1GHz
- Series
- -
- Current - Collector (Ic) (Max)
- 100mA
- Packaging
- Digi-Reel®
- DC Current Gain (hFE) (Min) @ Ic, Vce
- 40 @ 7mA, 3V
- Part Status
- Obsolete
- Voltage - Collector Emitter Breakdown (Max)
- 12V
- Power - Max
- 150mW
- Mounting Type
- Surface Mount
- Package / Case
- SC-70, SOT-323
- Transistor Type
- NPN
- Base Part Number
- NE85630
- Operating Temperature
- 150°C (TJ)
- Frequency - Transition
- 4.5GHz
- Supplier Device Package
- SOT-323
