SD02H0SB
DIP Switches
- Manufacturer No:
- SD02H0SB
- Manufacture:
- C&K
- Datasheet:
- SD02H0SB
- Description:
- SWITCH SLIDE DIP SPST 100MA 25V
In Stock
1222 pcs On sales
$2.06
Product Parameter
- Washable
- Yes
- Termination Style
- Gull Wing
- Packaging
- Tube
- Height Above Board
- 0.170" (4.33mm)
- Part Status
- Active
- Number of Positions
- 2
- Actuator Type
- Slide (Standard)
- Current Rating (Amps)
- 100mA
- Body Material
- Polyphthalamide (PPA)
- Operating Temperature
- -40°C ~ 85°C
- Mounting Type
- Surface Mount
- Actuator Level
- Flush, Recessed
- Pitch
- 0.100" (2.54mm), Full
- Contact Finish
- Gold
- Length
- 0.258" (6.55mm)
- Voltage Rating
- 25VDC
- Series
- SD
- Electrical Life
- 2,000 Cycles
- Circuit
- SPST
- Mechanical Life
- 2,000 Cycles
- Features
- Tape Seal
- Contact Material
- Beryllium Copper
