BXRH-40E8000-J-23
LED Lighting - COBs, Engines, Modules, Strips
- Manufacturer No:
- BXRH-40E8000-J-23
- Manufacture:
- Bridgelux
- Datasheet:
- BXRH-40E8000-J-23
- Description:
- 8000 LM NEUTRAL WHITE LED ARRAY
In Stock
0 pcs On sales
$0
Product Parameter
- Color
- White, Neutral
- Current - Test
- 2.5A
- Height
- 1.60mm
- Size / Dimension
- 19.00mm L x 19.00mm W
- Series
- H Series
- Temperature - Test
- 85°C
- CCT (K)
- 4000K 3-Step MacAdam Ellipse
- CRI (Color Rendering Index)
- 80
- Features
- -
- Light Emitting Surface (LES)
- 14.90mm Dia
- Lens Type
- Flat
- Lumens/Watt @ Current - Test
- 89 lm/W
- Packaging
- Tube
- Voltage - Forward (Vf) (Typ)
- 35.1V
- Wavelength
- -
- Flux @ Current/Temperature - Test
- 7789lm (Typ)
- Part Status
- Obsolete
- Configuration
- Square
- Current - Max
- 3.5A
- Type
- Chip On Board (COB)
- Viewing Angle
- 112°
