SRR7045-470M
Fixed Inductors
- Manufacturer No:
- SRR7045-470M
- Manufacture:
- Bourns, Inc.
- Package:
- Nonstandard
- Datasheet:
- SRR7045-470M
- Description:
- FIXED IND 47UH 950MA 150 MOHM
In Stock
26000 pcs On sales
$0.32
Product Parameter
- Package / Case
- Nonstandard
- Material - Core
- Ferrite
- Type
- Wirewound
- Base Part Number
- SRR7045
- Series
- SRR7045
- Size / Dimension
- 0.276" L x 0.276" W (7.00mm x 7.00mm)
- Ratings
- -
- DC Resistance (DCR)
- 150mOhm Max
- Q @ Freq
- 29 @ 2.52MHz
- Current - Saturation
- 780mA
- Packaging
- Tape & Reel (TR)
- Current Rating (Amps)
- 950mA
- Shielding
- Shielded
- Height - Seated (Max)
- 0.189" (4.80mm)
- Tolerance
- ±20%
- Operating Temperature
- -40°C ~ 125°C
- Inductance
- 47µH
- Supplier Device Package
- -
- Part Status
- Active
- Frequency - Self Resonant
- 11MHz
- Mounting Type
- Surface Mount
- Inductance Frequency - Test
- 100kHz
