SRP5030TA-2R2M
Fixed Inductors
- Manufacturer No:
- SRP5030TA-2R2M
- Manufacture:
- Bourns, Inc.
- Package:
- Nonstandard
- Datasheet:
- SRP5030TA-2R2M
- Description:
- FIXED IND 2.2UH 5.5A 35 MOHM SMD
In Stock
5320 pcs On sales
$0
Product Parameter
- Packaging
- Digi-Reel®
- Current Rating (Amps)
- 5.5A
- Shielding
- Shielded
- Height - Seated (Max)
- 0.118" (3.00mm)
- Tolerance
- ±20%
- Operating Temperature
- -40°C ~ 150°C
- Inductance
- 2.2µH
- Supplier Device Package
- -
- Part Status
- Active
- Frequency - Self Resonant
- 36MHz
- Mounting Type
- Surface Mount
- Inductance Frequency - Test
- 100kHz
- Package / Case
- Nonstandard
- Material - Core
- Carbonyl Powder
- Type
- Wirewound
- Base Part Number
- SRP5030TA
- Series
- SRP5030TA
- Size / Dimension
- 0.224" L x 0.205" W (5.70mm x 5.20mm)
- Ratings
- AEC-Q200
- DC Resistance (DCR)
- 35mOhm Max
- Q @ Freq
- 15 @ 100kHz
- Current - Saturation
- 9A
