SRN5040-4R7M
Fixed Inductors
- Manufacturer No:
- SRN5040-4R7M
- Manufacture:
- Bourns, Inc.
- Package:
- Nonstandard
- Datasheet:
- SRN5040-4R7M
- Description:
- FIXED IND 4.7UH 3.1A 35 MOHM SMD
In Stock
23000 pcs On sales
$0.17
Product Parameter
- Mounting Type
- Surface Mount
- Inductance Frequency - Test
- 100kHz
- Package / Case
- Nonstandard
- Material - Core
- Ferrite
- Type
- Wirewound
- Base Part Number
- SRN5040
- Series
- SRN5040
- Size / Dimension
- 0.197" L x 0.197" W (5.00mm x 5.00mm)
- Ratings
- -
- DC Resistance (DCR)
- 35mOhm Max
- Q @ Freq
- 15 @ 7.96MHz
- Current - Saturation
- 3.3A
- Packaging
- Tape & Reel (TR)
- Current Rating (Amps)
- 3.1A
- Shielding
- Semi-Shielded
- Height - Seated (Max)
- 0.157" (4.00mm)
- Tolerance
- ±20%
- Operating Temperature
- -40°C ~ 125°C
- Inductance
- 4.7µH
- Supplier Device Package
- -
- Part Status
- Active
- Frequency - Self Resonant
- 27MHz
