SRN4018-2R2M
Fixed Inductors
- Manufacturer No:
- SRN4018-2R2M
- Manufacture:
- Bourns, Inc.
- Package:
- Nonstandard
- Datasheet:
- SRN4018-2R2M
- Description:
- FIXED IND 2.2UH 2.9A 44 MOHM SMD
In Stock
77520 pcs On sales
$0.46
Product Parameter
- Package / Case
- Nonstandard
- Material - Core
- Ferrite
- Type
- Wirewound
- Base Part Number
- SRN4018
- Series
- SRN4018
- Size / Dimension
- 0.157" L x 0.157" W (4.00mm x 4.00mm)
- Ratings
- -
- DC Resistance (DCR)
- 44mOhm Max
- Q @ Freq
- 9 @ 7.96MHz
- Current - Saturation
- 3A
- Packaging
- Cut Tape (CT)
- Current Rating (Amps)
- 2.9A
- Shielding
- Semi-Shielded
- Height - Seated (Max)
- 0.071" (1.80mm)
- Tolerance
- ±20%
- Operating Temperature
- -40°C ~ 125°C
- Inductance
- 2.2µH
- Supplier Device Package
- -
- Part Status
- Active
- Frequency - Self Resonant
- 60MHz
- Mounting Type
- Surface Mount
- Inductance Frequency - Test
- 100kHz
