SRN3015TA-2R2M
Fixed Inductors
- Manufacturer No:
- SRN3015TA-2R2M
- Manufacture:
- Bourns, Inc.
- Package:
- 1212 (3030 Metric)
- Datasheet:
- SRN3015TA-2R2M
- Description:
- FIXED IND 2.2UH 1.7A 60 MOHM SMD
In Stock
6679 pcs On sales
$0
Product Parameter
- Part Status
- Active
- Inductance Frequency - Test
- 100kHz
- Mounting Type
- Surface Mount
- Package / Case
- 1212 (3030 Metric)
- Material - Core
- Ferrite
- Type
- Wirewound
- Base Part Number
- SRN3015TA
- Series
- SRN3015TA
- Size / Dimension
- 0.118" L x 0.118" W (3.00mm x 3.00mm)
- Ratings
- AEC-Q200
- DC Resistance (DCR)
- 60mOhm
- Q @ Freq
- 12 @ 100kHz
- Current - Saturation
- 1.7A
- Packaging
- Digi-Reel®
- Current Rating (Amps)
- 1.7A
- Shielding
- Semi-Shielded
- Height - Seated (Max)
- 0.059" (1.50mm)
- Tolerance
- ±20%
- Operating Temperature
- -40°C ~ 125°C
- Inductance
- 2.2µH
- Frequency - Self Resonant
- 64MHz
