1843A 0101000
Coaxial Cables (RF)
- Manufacturer No:
- 1843A 0101000
- Manufacture:
- Belden Inc.
- Datasheet:
- 1843A 0101000
- Description:
- COAX DUAL RG6 18AWG
In Stock
0 pcs On sales
$419.22
Product Parameter
- Wire Gauge
- 18 AWG (2)
- Jacket (Insulation) Diameter
- -
- Cable Group
- RG-6, Dual
- Jacket (Insulation) Material
- Polyethylene (PE)
- Part Status
- Active
- VoP, Velocity of Propagation
- 83
- Shield Type
- Foil, Braid
- Jacket Color
- Black
- Shield Coverage
- 100%, 60%
- Shield Material
- Aluminum
- Length
- 1000.0' (304.80m)
- Conductor Strand
- Solid (2)
- Series
- -
- Conductor Material
- Steel, Copper Coated
- Features
- Used in Aerial Applications
- Dielectric Diameter
- 0.180" (4.57mm)
- Impedance
- 75 Ohms
- Dielectric Material
- Foam Polyethylene (FPE)
- Cable Type
- Coaxial
- Operating Temperature
- -55°C ~ 80°C
