LDS100-48-H03
LED Drivers
- Manufacturer No:
- LDS100-48-H03
- Manufacture:
- Artesyn Embedded Technologies
- Datasheet:
- LDS100-48-H03
- Description:
- LED DRIVER CC/CV AC/DC 0-48V 2A
In Stock
0 pcs On sales
$0
Product Parameter
- Series
- LDS100 (100W)
- Voltage - Output
- 0 ~ 48V
- Weight
- 0.662 lb (300.28 g)
- Number of Outputs
- 1
- Dimming
- Analog
- Termination Style
- Wire Leads
- Ratings
- IP67
- Operating Temperature
- -40°C ~ 90°C
- Features
- OTP, OVP, SCP
- Voltage - Input (Max)
- 277VAC
- Topology
- AC DC Converter
- Voltage - Input (Min)
- 120VAC
- Approvals
- CE, CSA, EN, UL
- Current - Output (Max)
- 2A
- Efficiency
- 90%
- Part Status
- Obsolete
- Mounting Type
- Chassis Mount
- Power (Watts)
- 100W
- Type
- Constant Current, Voltage
- Size / Dimension
- 8.46" L x 1.65" W x 1.18" H (215.0mm x 42.0mm x 30.0mm)
