ADN4651BRWZ

Digital Isolators

Manufacturer No:: ADN4651BRWZ
Manufacture:: Analog Devices, Inc.
Package:: 20-SOIC (0.295", 7.50mm Width)
Datasheet:: ADN4651BRWZ
Description:: DIGITAL ISO 5KV 2CH LVDS 20SOIC

In Stock

366 pcs On sales

$12.39

Product Parameter

Series: iCoupler®

Voltage - Isolation: 5000Vrms

Data Rate: 600Mbps

Operating Temperature: -40°C ~ 125°C

Packaging: Tube

Inputs - Side 1/Side 2: 1/1

Technology: Magnetic Coupling

Rise / Fall Time (Typ): 350ps, 350ps (Max)

Part Status: Active

Supplier Device Package: 20-SOIC

Channel Type: Unidirectional

Pulse Width Distortion (Max): -

Mounting Type: Surface Mount

Propagation Delay tpLH / tpHL (Max): 4.5ns, 4.5ns

Isolated Power: No

Common Mode Transient Immunity (Min): 25kV/µs

Package / Case: 20-SOIC (0.295", 7.50mm Width)

Base Part Number: ADN4651

Voltage - Supply: 2.375V ~ 2.625V

Type: LVDS

Number of Channels: 2
